Features
- Support Z-Wave devices control, room control and scene control
- Control up to 120 Z-Wave devices
- Control up to 40 rooms, each room allows max of 120 devices
- Control up to 60 scenes, each scene allows 6 events and 12 actions
- Support Amazon Alex and Google Home
- Support IFTTT
- Support Geo-Sense
- Support plug & play IP cameras.(The specific IP camera models)
- Allows alarm notification for each Z-Wave devices and each scene
- Plug & play by ID/password
- Bundle with easy management software innocam home
- Push notification on iPhone/iPad and Android for device and scene events
- Internal real time clock
- Watchdog function to prevent system failure.
Technical Specifications
- POWER
DC 5V, 1.5A - PROCESSORS
RISC CPU - NETWORK INTERFACE
Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45 - Z-WAVE MODULE
Sigma Design 500 series module
Tx RF Power : -26 ~ 2 dBm
Range: 100 meters open site
Radio frequency : 868.42 MHz for Europe/China, 908.42 MHz for United States, 921.42 MHz for Australian/New Zealand, 922 MHz for Japan/Taiwan - BUTTONS
One reset button, to factory default settings
One WPS button for automatic WiFi setup - INDICATORS
One LED for Internet connection status indication
One LED for Ethernet connection indication
One LED for Z_wave signal indication - INSTALLATION, MANAGEMENT AND MAINTENANCE
Plug & play by ID/password
Management software Innocam home for multi-gateway management Firmware upgrades via FT - SUPPORTED PROTOCOLS
IPv4, HTTP, TCP, ICMP, UDP, SNTP, FTP, DHCP, ARP, DNS, PPPoE, etc. - ACCESSORIES (INCLUDED)
Power adaptor, RJ45 Ethernet cable, quick installation guide, ID/Password card - ALARM AND EVENT MANAGEMENT
Push notification on iPhone/iPad and Android devices - DIMENSIONS(HxWxD) AND WEIGHT
96 x 96 x 21 mm
129 g, incl. gateway bracket, excl. power adaptor - APPROVALS
EMC – CE, FCC Part 15 Subpart B Class B
Wireless RF – CE, FCC Part 15 Subpart C
Power supply: CE, FCC, UL, EN 60950 - OPERATING CONDITIONS
0-50 °C
Humidity 20 – 80% RH (non-condensing)
